Qasrawı, Atef Fayez Hasan
Loading...
Profile URL
Name Variants
Qasrawi, Atef Fayez Atef Fayez Hasan, Qasrawı Qasrawı,A.F.H. Qasrawi,A.F.H. Q., Atef Fayez Hasan Q.,Atef Fayez Hasan Atef Fayez Hasan, Qasrawi Qasrawi, Atef Fayez Hasan A.F.H.Qasrawı A.F.H.Qasrawi A., Qasrawi A.,Qasrawı Qasrawı, Atef Fayez Hasan Qasrawi, A. F. Qasrawi,A.F. Qasrawi, AF Qasrawi, Atef F. Qasrawi, Atef A. Qasrawi, Atef Fayez Qasrawi, Atef F. Qasrawi, Atef A. Qasrawi, Atef
Job Title
Doçent Doktor
Email Address
atef.qasrawi@atilim.edu.tr
Main Affiliation
Department of Electrical & Electronics Engineering
Status
Former Staff
Website
ORCID ID
Scopus Author ID
Turkish CoHE Profile ID
Google Scholar ID
WoS Researcher ID
No research topics data found.
Sustainable Development Goals
1NO POVERTY
0
Research Products
2ZERO HUNGER
0
Research Products
3GOOD HEALTH AND WELL-BEING
0
Research Products
4QUALITY EDUCATION
0
Research Products
5GENDER EQUALITY
0
Research Products
6CLEAN WATER AND SANITATION
0
Research Products
7AFFORDABLE AND CLEAN ENERGY
17
Research Products
8DECENT WORK AND ECONOMIC GROWTH
0
Research Products
9INDUSTRY, INNOVATION AND INFRASTRUCTURE
0
Research Products
10REDUCED INEQUALITIES
0
Research Products
11SUSTAINABLE CITIES AND COMMUNITIES
0
Research Products
12RESPONSIBLE CONSUMPTION AND PRODUCTION
0
Research Products
13CLIMATE ACTION
0
Research Products
14LIFE BELOW WATER
0
Research Products
15LIFE ON LAND
0
Research Products
16PEACE, JUSTICE AND STRONG INSTITUTIONS
1
Research Products
17PARTNERSHIPS FOR THE GOALS
0
Research Products
This researcher does not have a Scopus ID.
This researcher does not have a WoS ID.
No records found in other affiliations.
Scholarly Output
226
Articles
222
Views / Downloads
113/0
Supervised MSc Theses
0
Supervised PhD Theses
0
WoS Citation Count
2003
Scopus Citation Count
2018
Patents
0
Projects
0
WoS Citations per Publication
8.86
Scopus Citations per Publication
8.93
Open Access Source
17
Supervised Theses
0
| Journal | Count |
|---|---|
| Crystal Research and Technology | 16 |
| Journal of Electronic Materials | 15 |
| physica status solidi (a) | 12 |
| Materials Science in Semiconductor Processing | 11 |
| Journal of Alloys and Compounds | 11 |
Current Page: 1 / 11
Scopus Quartile Distribution
Competency Cloud
226 results
Scholarly Output Search Results
Now showing 1 - 10 of 226
Article Citation - WoS: 5Citation - Scopus: 5Structural and Dielectric Performance of the Ba(zn<sub>1/3< Perovskite Ceramics(Iop Publishing Ltd, 2019-07-26) Qasrawi, A. F.; Sahin, Ethem Ilhan; Emek, Mehriban; Kartal, Mesut; Kargin, SerdarIn this work, we have explored the antimony doping effects on the structural and dielectric properties of Ba(Zn1/3Nb2/3)O-3 ceramics (BZN). The ceramics displayed perovskite structures with a lattice constant that decreases with increasing Sb content. The antimony solubility limit of the BZN ceramics is x < 0.50. Belowthis limit and in the range of 0.30 <= x <= 0.40, the microstrain, the dislocation density and the stacking faults decreased and the crystallite size increases with increasing Sb content in the composition of BZN. When the limit is exceeded minor phases are predicted by software analysis and confirmed by the experimental techniques. The presence of these phases is also verified by the scanning electron microscopy and energy dispersive x-ray spectroscopy techniques. Increasing the Sb content is observed to decrease the value of the dielectric constant. The Sb doped BZN ceramics exhibits high dielectric quality factors that nominate it for applications in electronics as radio waves resonators.Article Citation - WoS: 7Citation - Scopus: 7In situ monitoring of the permanent crystallization, phase transformations and the associated optical and electrical enhancements upon heating of Se thin films(Elsevier Science Bv, 2019-09) Qasrawi, A. F.; Aloushi, Hadil D.In this work, the in situ structural transformations from amorphous to polycrystalline upon heating and the associated enhancements in the structural parameters of selenium thin films are studied by means of X-ray diffraction technique. The Se thin films which are grown onto ultrasonically cleaned glass substrate by the thermal evaporation technique under vacuum pressure of 10(-5) mbar exhibits structural transformation from amorphous to polycrystalline near 353 K. The films completed the formation of the structure which includes both of the hexagonal and monoclinic phases at 363 K. It is observed that the hexagonal phase dominates over the monoclinic as temperature is raised. Consistently, the thermally assisted crystallization process is accompanied with increase in the crystallite size, decrease in the microstrain, decrease in defect density and decrease in the percentage of stacking faults. The scanning electron microscopy measurements also confirmed the crystallinity of selenium after heating. The time dependent reputations of the crystallization test has shown that the achieved phase transitions and enhancements in structural parameters are permanent in selenium. Optically, the crystallization process is observed to be associated with redshift in the absorption spectra and in the value of the energy band gap. Electrically, the in situ monitoring of the electrical conductivity during the heating cycle has shown that the electrical conductivity stabilizes and exhibit a decrease in the acceptor levels from 566 to 321 meV after the crystallization was achieved.Article Citation - WoS: 5Citation - Scopus: 5Acoustic Phonons Scattering Mobility and Carrier Effective Mass in In<sub>6</Sub>s<sub>7< Crystals(Elsevier Science Sa, 2006-12) Qasrawi, A. F.; Gasanly, N. M.Systematic dark electrical resistivity and Hall coefficient measurements have been carried out in the temperature range of 170-320 K on n-type In6S7 crystals. The analysis of the electrical resistivity and carrier concentration reveals the intrinsic type of conduction with an average energy band gap of similar to 0.75 eV The carrier effective masses of the conduction and valence bands were calculated from the intrinsic temperature-dependent carrier concentration data and were found to be 0.565m(0) and 2.020m(0), respectively. The temperature-dependent Hall mobility was observed to follow the mu alpha T-3/2 law and was analyzed assuming the domination of acoustic phonons scattering. The acoustic phonons scattering mobility was calculated from the crystal's structural data with no assumptions. The experimental Hall mobility data of In6S7 crystals coincides with the theoretical acoustic phonons scattering mobility data with acoustic deformation potential of 6.4 eV. (c) 2006 Elsevier B.V. All rights reserved.Article Citation - WoS: 16Citation - Scopus: 17Dielectric Dispersion in Ga<sub>2</Sub>s<sub>3< Thin Films(Springer, 2016-08-17) Alharbi, S. R.; Qasrawi, A. F.In this work, the structural, compositional, optical, and dielectric properties of Ga2S3 thin films are investigated by means of X-ray diffraction, scanning electron microscopy, energy dispersion X-ray analysis, and ultraviolet-visible light spectrophotometry. The Ga2S3 thin films which exhibited amorphous nature in its as grown form are observed to be generally composed of 40.7 % Ga and 59.3 % S atomic content. The direct allowed transitions optical energy bandgap is found to be 2.96 eV. On the other hand, the modeling of the dielectric spectra in the frequency range of 270-1,000 THz, using the modified Drude-Lorentz model for electron-plasmon interactions revealed the electrons scattering time as 1.8 (fs), the electron bounded plasma frequency as similar to 0.76-0.94 (GHz) and the reduced resonant frequency as 2.20-4.60 x10(15) (Hz) in the range of 270-753 THz. The corresponding drift mobility of electrons to the terahertz oscillating incident electric field is found to be 7.91 (cm (2)/Vs). The values are promising as they nominate the Ga2S3 thin films as effective candidates in thin-film transistor and gas sensing technologies.Article Citation - WoS: 13Citation - Scopus: 13Design and Characterization of Tlinse<sub>2</Sub> Varactor Devices(Elsevier, 2011-07) Qasrawi, A. F.; Aljammal, Faten G.; Taleb, Nisreen M.; Gasanly, N. M.TlInSe2 single crystal has been successfully prepared by the Bridgman crystal growth technique. The crystal, which exhibits compositional atomic percentages of 25.4%, 25.2% and 49.4% for TI, In and Se, respectively, is found to be of tetragonal structure with lattice parameters of a=0.8035 and c=0.6883 nm. The crystals were used to design radio frequency sensitive varactor device. The temperature dependence of the current-voltage characteristics of the device allowed the calculation of the room temperature barrier height and ideality factor as 0.87 eV and as 3.2, respectively. Rising the device temperature increased the barrier height and decreased the ideality factor. This behavior was attributed to the current transport across the metal-semiconductor interface. The capacitance of the device is observed to increase with increasing voltage and increasing temperature as well. The temperature activation of the capacitance starts above 82 degrees C with a temperature coefficient of capacitance being 1.08 x 10 (3) K (1). Furthermore, the capacitance of the device was observed to increase with increasing frequency up to a maximum critical frequency of 4.0 kHz, after which the capacitance decreased with increasing frequency. The behavior reflected the ability of maximum amount of charge holding being at a 4.0 kHz. The analysis of the capacitance-voltage characteristics at fixed frequencies reflected a frequency dependent barrier height and acceptors density. The decrease in the barrier height and acceptors density with increasing frequency is mainly due to the inability of the free charge to follow the ac signal. (C) 2011 Elsevier B.V. All rights reserved.Article Citation - WoS: 2Citation - Scopus: 2Structural, Optical and Dielectric Performance of Molybdenum Trioxide Thin Films Sandwiched With Indium Sheets(inst Materials Physics, 2020) Abusaa, M.; Qasrawi, A. F.; Kmail, H. K.; Khanfar, H. K.; Department of Electrical & Electronics EngineeringIn this work, we report the enhancements in the structural, optical and dielectric properties of molybdenum trioxide that are achieved by insertion of 50 and 100 nm thick indium sheets between layers of MoO3. The films which are coated onto ultrasonically glass substrates under a vacuum pressure of 10 -5 mbar exhibited metal induced crystallization process upon insertion of indium sheets. Optically, indium sheets tuned the transmittance and reflectance, significantly, increased the absorption coefficient values and formed interbands in the band gap of MoO3. The energy band gap decreased with increasing indium sheets thickness. On the other hand, the insertion of indium layers into the structure of MoO3 is observed to improve the dielectric response of these films to values that nominate them for used in thin film transistor technology. In the same context, the analyses of the optical conductivity which are carried out with the help of Drude-Lorentz approach have shown that the presence of indium sheets can increase the optical conductivity and enhance the plasmon frequency and free charge carrier density of MoO3. The plasmon frequency is tuned in the range of 1.68-7.16 GHz making MoO3 films attractive for plasmonic applications.Article Citation - WoS: 3Citation - Scopus: 3Ytterbium Induced Structural Phase Transitions and Their Effects on the Optical and Electrical Properties of Znpc Thin Films(Springer, 2020-10-24) Qasrawi, A. F.; Zyoud, Hadeel M.In this work, the effects of ytterbium substrates of thicknesses of 150 (Yb-150) and 1000 nm (Yb-1000) on the structural, optical and electrical properties of zinc phthalocyanine (ZnPc) are investigated. While the Yb-150/ZnPc exhibited strained monoclinic structure, the Yb-1000/ZnPc thin films are observed to exhibit phase transitions from monoclinic to triclinic structure. Analysis which targeted observatories of the effects of the Yb-150 substrate on the optical properties indicated that the transparent Yb-150 substrate enhanced the light absorbability by more than 11 times at 1.27 eV. On the other hand, the impedance spectroscopy measurements on the nontransparent Yb-1000/ZnPc/Ag sandwiched structures have shown that these devices could exhibit negative capacitance (NC) effect in the frequency domain of 0.244-1.800 GHz. The NC effect is associated with resonance-anti-resonance response at 0.235 and 0.244 GHz, respectively. The structural, optical and electrical properties of the Yb/ZnPc interfaces indicate its applicability as optoelectronic and/or radio/microwave components.Article Citation - WoS: 2Citation - Scopus: 2Dielectric and Optoelectronic Properties of Inse/Cds Heterojunctions(Springer, 2018-08-10) Abusaa, M.; Qasrawi, A. F.; Shehada, Sufyan R.The effect of an InSe substrate on the structural, optical and dielectric properties of CdS/CdSe heterojunctions prepared by physical vapor deposition technique under vacuum pressure of 10(-8) bar are reported. The structural analysis carried out by x-ray diffraction revealed a strained type of growth of the CdS/CdSe heterojunction onto the InSe along the axis of the hexagonal lattice. The lattice mismatches and strained nature of the heterojunctions associated with the InSe participation causes a quantum confinement that results in a red shift in the energy band gap, enhanced near infrared (IR) light absorbability, and valence band offsets of 0.62eV and 0.53eV for the InSe/CdS and CdS/CdSe interfaces, respectively. In addition, a pronounced enhancement in the real part of the dielectric constant by 2.5 times is observed at 1.25eV. Furthermore, the Durde-Lorentz modeling of the optical conductivity of the CdS/CdSe and InSe/CdS/CdSe reveals significant increases in the drift mobility values from 43.8cm(2)/Vs at the CdS/CdSe interface to 100.0cm(2/)Vs upon replacement of glass by an amorphous InSe substrate. The other optical conduction parameters including the free carrier scattering time at the femtosecond level, the plasmon frequency and the free carrier density are also improved accordingly. The photocurrent illumination intensity dependence for the studied system showed that the presence of InSe increases the photocurrent values and changes the recombination mechanism from sublinear at the surface to trap-assisted recombination. The smart feature of the InSe/CdS/CdSe system is that the structurally controlled quantum confinement results in having mobile photocarriers arising from the enhanced absorbability and large dielectric response in the IR region.Article Citation - WoS: 3Citation - Scopus: 3Effect of Ionic Substitution on the Structural, Dielectric and Electrical Properties of Bismuth Zinc Niobate Ceramics(Korean Assoc Crystal Growth, inc, 2012) Qasrawi, A. F.; Abu Je'ib, Hussein A.; Mergen, A.; Mergenc, A.; Qasrawia, A.F.; Department of Electrical & Electronics EngineeringThe effects of tin substitution on the structural, dielectric and electrical properties of the Bi1.5Zn0.92Nb1.5O6.92 pyrochlore ceramics have been investigated. Tin atoms was substituted in the A (Bi1.5Zn0.46)-site instead of zinc and in the B ((Zn0.46Nb1.5)-site instead of niobium in accordance to the chemical formulae Bi1.5Zn0.92Nb1.5-xO6.92-x/2 and (Bi1.5-x/3Zn0.46-3x/2Snx)(Nb1.5Zn0.46)O-6.92, for 0.00 <= x <= 0.40 and 0.00 <= x <= 0.60, respectively. A relative single phase formation of the structures was possible for x values less than 0.25 and less than 0.10. Pronounced tunability in the dielectric constant values associated with very low dielectric loss are obtainable by Sn substitution. Furthermore, a frequency invariant but linearly varying temperature dependent dielectric constant is observed. The electrical conductivity decreased by two and one order of magnitude for the A and B-site substitutions, respectively. The temperature-dependent conductivity analysis in the temperature region of 300-500 K, reflected the existence of shallow and deep impurity energy levels being created by the doping process.Article Citation - WoS: 7Citation - Scopus: 7Structural and Dielectric Properties of Ba<sub>1-<i>x</I>< Solid Solutions(Wiley-v C H verlag Gmbh, 2020-10-25) Qasrawi, A. F.; Sahin, Ethem Ilhan; Abed, Tamara Y.; Emek, MehribanHerein, lanthanum doping effects on the structural, dielectric, and electrical properties of Ba1-xLax(Zn1/3Nb2/3)O-3 (BZN) solid solutions are focused upon. The La contents which are varied in the range of 0.02-0.20 exhibit a solubility limit of x = 0.02. Although minor phases of Ba5Nb4O15 and Ba3LaNb3O12 appear for samples doped with La contents of x = 0.05 and x = 0.10, they play no remarkable role for the enhanced structural and dielectric properties of BZN. The La doping content of x = 0.02 succeeds in increasing the crystallite size by 51.16% and lowering the microstrain by 34.18% and defect concentration by 63.10%. La-doped BZN ceramics display higher values of relative density and electrical conductivity. The analyses of the dielectric spectra as a function of temperature display dielectric relaxation behavior above 120 degrees C. In the temperature range of 20-120 degrees C, La doping changes the temperature coefficient of dielectric constants from +30 ppm degrees C-1 in pure samples to -341 ppm degrees C-1 in samples doped with La contents of x = 0.10. The enhancements in structural parameters, density values, and dielectric responses that are achieved via La doping make BZN ceramics more suitable for electronic device fabrication.
